MIL-PRF-1/1105A
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
.125 x 45° approx
3.20 x 45° approx
A
B
2.887
2.897
73.33
73.58
C
1.443
1.453
36.65
36.91
D
8-32 Tap (M) holes each figure
E
3.214
3.224
81.64
81.89
F
.717
.727
18.21
18.47
G
1.075
1.085
27.30
27.56
H
1.370
1.380
34.80
35.05
J
.120
.130
3.05
3.30
K
1.262
1.282
32.05
32.56
L
---
1.375
---
34.92
M
.250 Nom
6.35 Nom
NOTE: Exhaust stem not to extend beyond flange.
FIGURE 2. Input and output flanges.
5
