MIL-PRF-1/1105A
TABLE I. Testing and inspection - Continued.
Limits
Inspection
Method
Conditions
Symbol
Min
Max
Unit
F = 9,000 MHz ± 0.5%;
µs
t
---
7.0
Recovery time (1)
4471
po = 200 kw ± 10%;
tp = 1.0 µs ± 0.05 µs;
prr = 1,000;
Ii = 100 µA dc on each ignitor
F = 9,000 MHz ± 0.5%;
µs
t
---
3.0
Recovery time (2)
4471
po = 65 kw ± 10%;
tp = 1.0 µs ± 0.05 µs;
prr = 1,000;
Ii = 100 µA dc on each ignitor
δ
F = 9,000 MHz ± 0.1%;
---
1.2
---
High level VSWR
4474
po = 40 kw ± 10%;
tp = 1.0 µs ± 0.05 µs;
prr = 1,000;
Ii = 100 µA dc on each ignitor
F = 9,000 MHz ± 5%;
t
500
---
hours
Life test
---
Ii = 100 µA dc on each ignitor
po = 200 kw ± 10%;
tp = 1.0 µs ± .05 µs;
prr = 1,000;
Group D
F = 9,000 MHz ± 0.1%
Life test end point:
---
µs
Recovery time (1)
4471
t
---
10
µs
Recovery time (2)
4471
t
---
5
Flat leakage power
4452
pf
---
20
mw
Spike leakage energy
4452
Ws
---
.15
erg
Insertion loss
4116
---
---
1.0
dB
1/ There shall be no evidence of shorts of the ignitor electrodes as indicated by a short indicator during vibration.
2/ Ignitor interaction is measured with the specified ignitor current adjusted on both ignitor electrodes.
3/ Ignitor ignition time shall be measured separately for each ignitor electrode.
4/ Ignitor voltage drop shall be measured separately for each ignitor electrode.
5/ All measurements that include short-slot hybrids shall be made with gaskets bolted between input and output flanges of tube and
mating flanges.
