INCH-POUND
MIL-PRF-1/1065G
14 July 2009
.
SUPERSEDING
MIL-E-1/1065F
25 June 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 5BCP7
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Miniaturized, magnetic deflection and focus.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
Eb1
Ehk
Rg1
Alt
MegΩ
Unit:
V
V dc
V dc
V dc
ft
180
Maximum:
6.9
0
11,000
80,000
1.5
Minimum:
5.7
-200
5,000
---
---
---
Test condition:
6.3
Adjust
6,000
---
---
---
See footnotes at end of table I.
GENERAL:
1/
Qualification - Required.
AMSC N/A
FSC 5960
