MIL-PRF-1/1056F
Dimensions
Ltr
Inches
Millimeters
Ltr
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
A
13.370
13.380
339.60
339.85
L
.092
.096
2.34
2.44
35°
35° 30'
35°
35° 30'
B
4.029
4.033
102.34
102.44
M
C
.995
1.005
25.27
25.53
N
6.271
6.291
159.28
159.79
D
1.015
1.019
25.78
25.88
P
8.495
8.505
215.77
216.03
E
1.495
1.505
37.97
38.23
Q
.495
.505
12.57
12.83
37° 30'
38° 30'
37° 30'
38° 30'
.120 x 44°
.130 x 45°
3.05 x 44°
3.30 x 45°
F
R
30' CHAM
30' CHAM
30' CHAM
30' CHAM
G
3.592
3.596
91.24
91.34
89° 30'
90° 30'
89° 30'
90° 30'
89° 30'
90° 30'
89° 30'
90° 30'
H
S
35° 30'
36° 30'
35° 30'
36° 30'
J
T
1.995
2.005
50.67
50.93
K
.995
1.005
25.27
25.53
NOTE
1.
All dimensions are in inches.
Unless otherwise specified, tolerances shall be ± .016 inch (0.041 mm) on fractions ± .005 inch (0.13 mm) on decimals,
2.
and ± .5° on angles.
3.
Instructions for use: Reject if bulb does not rest on flat 'A-A' when bulb neck is seated in V block.
FIGURE 3. Bulb contour gauge.
7
