MIL-PRF-1/1056F
Dimensions
Ltr
Inches
Millimeters
Ltr
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
A
14.187
14.687
360.35
373.05
K
3.242
3.258
82.35
82.75
B
.115
.135
2.92
3.43
L
6.484
6.516
164.69
165.51
44°30'
45°30'
44°30'
45°30'
C
M
5.304
5.320
134.72
135.13
D
1.750
2.250
44.45
57.15
N
10.609
10.641
269.47
270.28
E
.492
.508
12.50
12.90
P
6.273
6.289
159.33
159.74
F
.052
.072
1.32
1.83
Q
12.546
12.578
318.67
319.48
G
3.750
4.250
95.25
107.95
R
39.875 R
40.125 R
1012.83 R
1019.18 R
H
.984
1.016
24.99
25.81
S
39.875 R
40.125 R
1012.83 R
1019.18 R
J
2.992
3.008
76.00
76.40
NOTE
1.
All dimensions are in inches.
R2 shall be equal to the absolute value of R1 ± .050 inch (1.27 mm) ± .002 inch (0.05 mm).
2.
3.
Instructions for use: Contour of face shall be checked with gauge at two orientations approximately 90 degrees. Reject if
1
gap between bulb face and gauge points B, B , or C is greater than .100 inch (2.54 mm). Reject if bulb does not seat on
1
steps A and A .
FIGURE 2. Faceplate gauge.
