INCH-POUND
MIL-E-1/1315E
17 January 2014
SUPERSEDING
MIL-E-1/1315D
1 April 1977
MILITARY SPECIFICATION SHEET
ELECTRON TUBE, MAGNETRON
TYPE 6517 1/
Inactive for new design
after 21 July 1997.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described
herein shall consist of this specification sheet and MIL-PRF-1.
DESCRIPTION: Mechanically tunable, 1,250-1,350 Mhz, pulsed type, air-cooled, 1.0 MW, integral magnet.
ABSOLUTE RATINGS:
Parameter:
ib
Pi
pi
Du
tpc
eb
If
tk
Unit:
a
kW
Mw
--
µs
kv
A
sec
Maximum:
60
4.3
3.5
.0013
4.62
70
90
---
Minimum:
35
---
---
---
1.0
---
---
600
Note 2
Output
Parameter:
VSWR
Tuner-torque
Anode T
Bushing T
Pressurization
ℓbf/in
2
Unit:
---
in-oz
°C
°C
Maximum:
1.5
125
100
150
45
Minimum:
---
---
---
---
11
Note 4
Note 5
Note 5
Note 6
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1
Input bushing:
See note 7
Cathode:
Unipotential
Mounting position: See note 9
Weight:
90 pounds
TEST CONDITIONS:
Parameter:
If
tk
Du
tpc
Ib
Test Frequencies
Unit:
A
sec
---
µs
mAdc
F1=1250 ± 2 MHz
Tolerance:
---
---
---
0.3
± 2.5
F2=1300 ± 2 MHz
75
600
.00125
3.0
62.5
F3=1350 ± 2 MHz
Note 15
GENERAL:
First Article Test Required. See note 21.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
1/ Replaces type RK6517/QK-358 (NSN 5960-00-507-6096), Cardion P/N 400615 (NSN 5960-00-925-8159)
AMSC N/A
FSC 5960
