INCH-POUND
MIL-PRF-1/952H
18 June 2008
SUPERSEDING
MIL-E-1/952G
17 February 1981
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 6AU6WC 1/
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
Inactive for new design
after 30 April 1997
The requirements for acquiring the electron tube described
herein shall consist of this document and MIL-PRF-1.
DESCRIPTION:
Pentode, miniature, RF sharp cutoff.
Outline
--- 5-2 (EIA).
Base
--- E7-1.
Envelope --- T5-1/2.
Cathode --- Coated unipotential.
Base connections:
Pin No.
---
1
2
3
4
5
6
7
Element
---
g1
g3
h
h
a
g2
k
int ed
ABSOLUTE- RATINGS:
Parameter:
Ef
Eb
Ec1
Ec2
Ec3
Ehk Rk
Unit:
V
Vdc
Vdc
Vdc
Vdc
v Ohms
Maximum:
6.9
330
0,-50
165
0
100 ---
Minimum:
5.7
---
---
---
---
---
---
Test conditions:
6.3
250
0
150 (see note 2)
---
68
ABSOLUTE- RATINGS:
Parameter:
Rg1 Icl
Pp
Pg2
TE
Alt
Unit:
Neg mAdc
W
W
°C
ft
Maximum:
0.5 1.0
3.3
0.72
165 (See note 1)
Minimum:
---
---
---
---
---
---
Test conditions:
---
---
---
---
---
---
GENERAL:
Qualification: Not Required
Reliable tube
1/ Formerly tube type 6AU6WB
AMSC N/A
FSC 5960
