INCH-POUND
MIL-PRF-1/95E
14 March 2013
SUPERSEDING
MIL-PRF-1/95D
22 January 2007
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 5886
Inactive for new design
after 7 March 1997.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described
herein shall consist of this specification sheet and MIL-PRF-1.
DESCRIPTION: Pentode, subminiature, filamentary electrometer.
Outline
----
2-1 (EIA).
Base
----
Pinch press (5 leads).
Envelope
----
T2X3.
Cathode
----
Coated filament.
Base connections:
Pin No.
----
1
2
3
4
7
Element
----
a
g2
+f, 1g3
-f, 2g3
g1
ABSOLUTE RATINGS:
Parameter:
Ebb
Ef
Eb
Ec2
Ec1
Ik
R1
Alt
µA dc
Unit:
V dc
V dc
V dc
V dc
V dc
Ohms
ft
Maximum:
---
1.5
22.5
22.5
---
300
---
10,000
Minimum:
---
1.0
---
---
---
---
---
---
Test conditions:
22.5
1.25
---
---
-3.0
---
60,000
---
(triode connected)
GENERAL:
Qualification - Not required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
