INCH-POUND
MIL-PRF-1/924H
18 June 2008
SUPERSEDING
MIL-E-1/924G
15 August 1977
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 5R4WGB
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
Inactive for new design
after 21 July 1997
The requirements for acquiring the electron tube described
herein shall consist of this document and MIL-PRF-1.
DESCRIPTION:
Full-wave rectifier, high vacuum.
Outline --- See figure 1.
Envelope --- T14.
Cathode --- Coated filament.
Base connections:
Pin No.
---
1
2
4
6
8
Element
---
nc
f
2a
1a
f
ABSOLUTE RATINGS:
Parameter:
Ef
Epp/a
epx
R1
C1
Unit:
V ac
V ac
V
Ohms
µf
(Note 1)
Maximum:
5.0 ±10%
---
1,850
---
4
5.0 ±10%
---
2,150
---
---
5.0 ±10%
---
2,300
---
---
5.0 ±10%
---
2,800
---
4
5.0 ±10%
---
2,900
---
---
Minimum:
---
---
---
---
---
Test conditions:
5.0
850
---
3,500
4
ABSOLUTE RATINGS:
Parameter:
Io
ib/a
tk
TE
Alt
Unit:
mA dc
mA
sec
°C
ft
(Notes 4 and 5)
Maximum:
275
---
10
260
60,000
275
700
10
260
40,000
275
Note 2
10
260
40,000
165
---
10
260
40,000
190
Note 3
10
260
35,000
Minimum:
---
---
---
---
---
Test conditions:
---
---
---
---
---
GENERAL:
Qualification: Not required.
Reliable tube.
AMSC N/A
FSC 5960
