MIL-PRF-1/906E
TABLE I. Testing and inspection.
MIL-STD-
1311
Inspection
Symbol
Limits
Unit
Method Notes
Conditions
Acceptance
level
Min
Max
Conformance inspection,
part 1
Npm
60
---
N/t
5/
0.65
6201
t = 2 minutes
Background, contamination
and photosensitivity
5/ 6/
t = 2 minutes
0.65
N/t
---
20
Npm
Photosensitivity
6201
0.65
Es
---
640
V dc
Starting voltage
6211
---
Pulse amplitude
= 1 volt; R1 = C1
= C2 = 0; R2 = 1 Meg;
C3 = 0.01 µF;
Nps = 200 (max)
0.65
Ps
---
0.2
%/V dc
Relative plateau slope
6216
---
Voltage range = 660
to 760 V dc
End-of-plateau voltage
6216
14/
Ps = 0.3%/V dc
0.65
Ee
800
---
V dc
Plateau length
6216
13/
0.65
Pl
200
---
V dc
6221
---
t = 2 minutes
0.65
N/t
85
115
Nps
Response count rate and
current (gamma)
Conformance inspection,
part 2
Response count rate and
8/
---
6221
---
t = 2 minutes
---
---
N/t
current (beta)
---
Ib
---
5
Response count rate and
6221
---
Gamma (radium);
µA dc
current
rate = 5 mr/hr;
Ebb = 710 V dc
---
eo
2.5
---
v
Pulse amplitude (1)
6226
---
Ebb = 675 V dc;
Nps = 200 (max);
R1 = 0.9 Meg ± 10%;
R2 = 0.1 Meg ± 10%;
C1 = 330 pF ± 10% ;
C2 = 3,000 pF ± 10%;
C3 = 0.01 µF ± 10%;
multiply oscilloscope
reading by 10
---
eo
---
65
v
Pulse amplitude (2)
6226
---
Ebb = 725 V dc;
Nps = 200 (max);
R1 = 0.9 Meg ± 10%;
R2 = 0.1 Meg ± 10%;
C1 = 330 pF ± 10%;
C2 = 3,000 pF ± 10%;
C3 = 0.01 µF ± 10%;
multiply oscilloscope
reading by 10
