INCH-POUND
MIL-PRF-1/876G
27 March 2000
SUPERSEDING
MIL-PRF-1/876F
21 September 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, POWER
TYPE 8165
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Tetrode.
See figure 1.
Mounting position: Vertical, base down or up.
W eight: 3-ounces (85 grams) nominal.
ABSOLUTE RATINGS: C Telegraphy
Parameter:
F1
Ef
Eb
Ec1
Ec2
Ib
Pp
Pg1
Pg2
T(seal)
TE
°C
°C
Unit:
MHz
V ac
V dc
V dc
V dc
mA dc
W
W
W
Maximum:
150
6.3
3,000
-500
400
150
65
5
10
200
225
Minimum:
---
5.7
---
---
---
---
---
---
---
---
---
Test conditions:
---
6.0
1,000
Adj
400
65
---
---
---
2/
---
See footnotes at end of table I.
________________________________________________________________________________________________
GENERAL:
Qualification: Required.
AMSC N/A
1 of 5
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
