INCH-POUND
MIL-PRF-1/7J
4 January 2008
SUPERSEDING
MIL-E-1/7H
17 February 1981
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 5726
Inactive for new design
after 7 March 1997
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
Requirements for acquiring the electron tube described herein
shall consist of this specification sheet and MIL-PRF-1.
Twin diode, miniature.
DESCRIPTION:
Outline
--- 5-1 (EIA).
Base
-- - E7-1.
Envelope --- T5-1/2.
Cathode --- Coated unipotential.
Base connections:
Pin No. ---
1
2
3
4
5
6
7
Element ---
1k
2a
h
h
2k
sd
1a
ABSOLUTE RATINGS:
Parameter:
Ef
Epp/a
epx
Ehk
R1
C1
Io/a
ib/a
i surge/a
TE
Alt
μF
Unit:
V
V ac
v
v
Ohms
mA dc
ma
ma
°C
ft
Maximum:
6.9
---
360
360
---
---
9.0
54
320
+165
Note 2
(see note 1)
Minimum:
5.7
---
---
---
---
---
---
---
---
---
---
Test conditions:
6.3
165
---
---
11,000
8
---
---
---
---
---
GENERAL:
Qualification: Not required.
Reliable tube.
AMSC N/A
FSC 5960
