MIL-PRF-1/689G
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Qualification inspection
L
Bulb contact: J1-22
M
Base: B12-37
Conformance inspection, part 2
A
16.563
16.938
420.70
430.23
B
5.156
5.344
130.96
135.75
C
1.938
2.063
49.23
52.40
D
2.250 R
57.15
F
6.000
6.500
152.40
165.10
G
2.063
2.563
52.40
65.10
10°
10°
H
Reference Dimensions (see note 3)
E
10.281
261.14
J
27.813R
706.14
K
0.875
22.23
NOTES:
1.
Dimensions are in inches with metric equivalents (in mm) for comparison.
2.
Useful screen radius.
3.
Reference dimensions are for information only and are not required for inspection purposes.
FIGURE 1. Outline drawing of electron tube types 5ADP1, 5ADP2, 5ADP7 AND 5ADP14.
6
