INCH-POUND
MIL-PRF-1/689G
3 February 2012
SUPERSEDING
MIL-PRF-1/689F
6 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBES, CATHODE RAY
TYPES 5ADP1, 5ADP2, 5ADP7 AND 5ADP14
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Electrostatic deflection and focus with post accelerator.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
ed
Eb1
Eb2
Eb3
Rg
Zd
Eb3
Ehk
Alt
Eb2
MegΩ
MegΩ
Unit:
V
V dc
v
V dc
V dc
V dc
Ratio
V dc
ft
±180
Maximum:
All
6.9
0, -200
550
1,100
2,850
6,600
1.5
1.0
2.3
50,000
Minimum:
P1
5.7
---
---
---
1,500
1,500
---
---
---
---
---
P2, P7,
5.7
---
---
---
1,500
3,000
---
---
---
---
---
P14
Test
P1
6.3
Adjust
---
Focus
1,500
3,000
---
---
---
---
---
conditions:
P2, P7
6.3
Adjust
---
Focus
2,000
4,000
---
---
---
---
---
P14
__________________________________________________________________________________________________
GENERAL:
Qualification - Required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
For Parts Inquires call Parts Hangar, Inc (727) 493-0744
