INCH POUND
MIL-PRF-1/592C
30 September 2009
SUPERSEDING
MIL-PRF-1/592B
9 February 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPES 5BP1A AND 5HP1A
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Electrostatic deflection and focus.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
ed
Eb1
Eb2
Light output
Rg
Zd
Alt
MegΩ
MegΩ
Unit:
V
V dc
v
V dc
V dc
fL
ft
Maximum:
6.9
0
500
1,100
2,200
---
1.5
1.0
10,000
Minimum:
5.7
-125
---
---
1,500
2.0
---
---
---
Test
6.3
Adj
---
Focus
1,500
---
---
---
---
conditions:
____________________________________________________________________________________________
GENERAL:
Qualification - Required
AMSC N/A
FSC 5960
