INCH POUND
MIL-PRF-1/588B
29 January 1999
SUPERSEDING
MIL-E-1/588A
18 December 1974
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 2AP1A
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Electrostatic deflection and focus.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE-RATINGS:
Parameter:
Ef
Ec1
ed
Eb1
Eb2
Light
Rg
Zd
Ehk
Alt
output
Unit:
V
V dc
v
V dc
V dc
fL
Meg
Meg
V dc
ft
Maximum:
6.9
0
660
550
1,100
---
1.5
1.0
-125
10,000
Minimum:
5.7
-125
---
---
500
2.0
---
---
---
---
Test conditions:
6.3
Adj
---
Focus
1,000
---
---
---
---
---
GENERAL:
Qualification - Required.
AMSC N/A
1 of 5
FSC 5960
