MIL-PRF-1/505H
Dimensions in inches with metric
equivalents (mm) in parentheses
Ltr
Minimum
Maximum
Conformance inspection, part 2
A
2.500 (63.50)
2.688 (68.28)
B
0.750 (19.05)
Pin Connections
C
1.703 (43.26)
2.094 (53.19)
Pin No.
Element
Conformance inspection, part 3 (see note)
1
k
D
Cap: Skirted miniature C1-3
2
k
K
Base: E7-1
3
k
E
0.245 (6.22)
0.255 (6.48)
4
k
F
86.5°
93.5°
5
k
Reference dimensions
6
k
G
0.600 (15.24)
7
k
H
0.420 (10.67)
cap
a
J
0.281 (7.14)
NOTE:
Dimensions shall be checked during the initial production and once each succeeding 12-calendar months in which there is production.
An accept on zero defect sampling plan shall be used, with sample of three tubes with an acceptance number of zero. In the event of
failure, the test will be made as a part of conformance inspection, part 2, with an acceptance level of 6.5 (see note 8). The "12-calendar
month" sampling plan shall be reinstated after three consecutive samples have been accepted.
FIGURE 1. Outline drawing of electron tube type 5962.
4
