MIL-PRF-1/501C
TABLE 1. Testing and inspection.
Inspection
Method
Notes
Conditions
Symbol
Limits
Limits
Units
Min
Max
Qualification inspection
Base material insulating
1216
---
---
---
Zone 5 (minimum)
---
---
quality
Pressure (implosion)
1141
---
---
---
---
---
Vibration
5111
---
Width
---
1.0
mm
Direct-interelectrode
1331
---
Cg1
g1 to all
---
11.0
pF
capacitance
C1D2
D1 to D2
---
4.0
pF
C3D4
D3 to D4
---
4.0
pF
CD1
D1 to all
---
15.0
pF
CD2
D2 to all
---
11.0
pF
CD3
D3 to all
---
10.0
pF
CD4
D4 to all
---
11.0
pF
Deflection-factor uniformity
5248
---
---
---
---
---
Focusing voltage,
5246
Eb1
---
240
450
V dc
zero-bias
Neck and bulb alignment
5101
Diam
---
---
1.87
Inches
(electrostatic types)
Cathode illumination
5216
---
---
---
---
---
Conformance inspection, part 1
Bulb, screen and faceplate quality
5106
---
---
---
---
---
Voltage breakdown
5201
---
---
---
---
---
Voltage breakdown
5201
---
---
---
---
---
(electrostatic types)
Gas "cross"
5206
1
Light = 4 fL
---
---
---
---
Light output
5221
1
Light
4.0
---
fL
Modulation
5223
---
Light = 4 fL
---
45
V dc
Ec1
Spot displacement (leakage)
5231
---
---
7.0
mm
Displ
Spot position (electrostatic
5231
---
---
15.0
mm
---
deflection)
Grid cutoff voltage
5241
---
---
-67.5
V dc
Ec1
Grid No. 1 leakage current
5251
---
---
---
---
---
Anode No. 2 leakage
5251
---
---
---
---
---
current
See notes at end of table I.
