MIL-PRF-1/30C
Dimensions
Letter
Notes
Minimum
Maximum
Inches
mm
Inches
mm
Conformance inspection, part 2
A
.995
25.27
1.005
25.53
1, 3
B
.740
18.80
.750
19.05
1, 3
C
.695
17.65
.725
18.42
---
D
.045
1.14
.055
1.40
1, 2
E
---
---
.660
16.76
1
F
.197
5.00
.207
5.26
1, 2
G
---
---
2.375
60.33
---
H
1.405
35.69
1.475
37.47
---
J
1.200
30.48
1.230
31.24
---
K
---
---
.900
22.86
---
L
---
---
.815
20.70
---
M
---
---
.887
22.53
---
N
.080
2.03
---
---
2
P
.175
4.45
.195
4.95
---
Q
.090
2.29
---
---
2
R
.375
9.53
.425
10.80
---
S
---
---
.190
4.83
---
U
.007
0.18
.013
0.33
---
NOTES:
1.
Reference diameter "F" to be concentric with respective diameters as follows: Diameter "A" .040 (1.02 mm) FIR,
diameter "B" .030 (0.76 mm) FIR, diameter "D" .030 (0.76 mm) FIR, diameter "E" .060 (1.52 mm) FIR. Full indicator
reading includes out of roundness and tilt of components.
2.
Areas designated by dimensions "D", "F", "N", and "Q" must be clean and free from glass.
3.
Reference diameter "A" to be concentric with diameter "B" within .030 (0.76 mm) FIR.
4.
This surface to be flat within .005 (0.13 mm).
FIGURE 1. Outline drawing of electron tube type 2C36 - Continued.
