INCH-POUND
MIL-PRF-1/30C
26 April 2013
SUPERSEDING
MIL-PRF-1/30B
22 January 2007
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, MICROWAVE, NEGATIVE GRID
TYPE 2C36
Inactive for new design
after 7 March 1997.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described
herein shall consist of this specification sheet and MIL-PRF-1.
DESCRIPTION: Triode, planar.
See figure 1.
Mounting position: Any.
Weight: 0.4 ounce nominal.
ABSOLUTE RATINGS: UHF oscillator, anode pulse modulated.
Parameter:
F1
Ef
Eb
Ib
eb
Pp
tk
T(seal)
Rk
Du
tp
°C
µs
Unit:
MHz
V
V dc
mA dc
v
W
sec
Ohms
---
Maximum:
1,200
6.6
350
16.0
1,500
5.0
---
175
---
0.004
2.0
Minimum:
---
6.0
---
---
---
---
---
---
---
---
---
Test conditions:
---
6.3
180
12.0
---
---
300
---
400
---
---
GENERAL:
Qualification - Not required.
Holding period (MIL-STD-1311): t = 168 hours.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
