INCH POUND
MIL-PRF-1/299G
23 November 2010
SUPERSEDING
MIL-PRF-1/299F
6 September 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE , GAS SWITCHING
TYPE 5927
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1 .
DESCRIPTION: TR, bandpass, frequency range 3,100 to 3,500 MHz, incident power 825 kw.
ABSOLUTE RATINGS:
Incident power
Ii
Ebb
Du
Alt
Parameter:
A dc
Unit:
kw
V dc
---
Ft
Maximum:
---
200
-700
0.001
10,000
Minimum:
100
---
-500
---
---
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1.
Mounting:
153-JAN (or equivalent) 268-JAN.
Mounting position:
Any.
TEST CONDITIONS:
Frequency
F
MHz
F1
3,100
0.1 %
F2
3,300
0.1 %
F3
3,425
0.1 %
F4
3,500
0.1 %
Parameter:
Incident power
Ii
tp1
tp2
F
Du
A dc
s
s
Unit:
kw
---
---
Test condition 1:
Maximum:
---
---
1.15
---
---
---
50
---
1.00
---
F2
0.001
Minimum:
---
---
0.85
---
---
---
Test condition 2:
Maximum:
220
---
1.15
0.60
---
---
200
200
1.00
0.50
F2
0.001
Minimum:
180
---
0.85
0.40
---
---
Test condition 3:
Maximum:
825
---
---
---
---
---
750
200
---
---
F3
0.001
Minimum:
675
---
---
---
---
---
GENERAL:
Qualification - Required.
.
AMSC N/A
FSC 5960
