MIL-PRF-1/296E
Dimensions
Dimensions
Inches
Millimeters
Inches
Millimeters
Ltr
Min
Max
Min
Max
Ltr
Min
Max
Min
Max
Conformance inspection, part 1
D
0.859
0.891
21.82
22.63
J
1.744
1.756
44.30
44.60
E
1.000 REF
25.4 REF
M
G
0.638
0.642
16.21
16.31
1.218 Nom
30.94 Nom
P
H
---
0.828
---
21.03
0.061
0.065
1.55
1.65
Q
K
---
0.875
---
22.23
0.400
0.402
10.16
10.21
L
0.609 Nom
15.47 Nom
Conformance inspection, part 2
N
0.020
0.030
0.51
0.76
A
---
2.187
---
55.55
R
0.028
0.030
0.71
0.76
B
0.608
0.612
15.44
15.54
C
---
1.375
34.
34.93
S
8-32 UNC-28 THD
These Dimensions apply to 5846 only.
FIGURE 1. Outline drawing of tube types 1Q22, 1Q23, 1Q24, 5846, 6040, and 6041.
