MIL-PRF-1/1756B
Dimensions
LTR
Notes
Millimeters
Inches
Conformance inspection, part 2
Min
Max
Min
Max
A
44.96
46.48
1.770
1.830
B
----
37.47
----
1.475
C
----
35.69
----
1.405
D
30.91
31.93
1.217
1.257
F
22.66
23.67
0.892
0.932
G
11.73
12.12
0.462
0.477
J
19.46
20.98
0.766
0.826
N
26.04
26.29
1.025
1.035
3, 10, 11
R
16.64
16.89
0.655
0.665
3, 10, 11
T
5.41
5.66
0.213
0.223
3, 7, 10, 11
U
8.00
8.26
0.315
0.325
3, 7, 10, 11
Conformance inspection, part 3 5/
E
3.18
4.70
0.125
0.185
H
----
1.02
----
0.040
K
0.64
1.17
0.025
0.046
9
L
31.34
32.11
1.234
1.264
M
29.97
30.35
1.180
1.195
P
19.10
20.12
0.752
0.792
12
Q
16.51
21.59
0.650
0.850
S
----
13.84
----
0.545
V
----
2.18
----
0.086
W
----
2.54 RAD
----
0.100 RAD
Electrode contact areas
2
AA
0.89
9.17
0.035
0.361
AB
28.27
30.30
1.113
1.193
AC
33.30
38.23
1.311
1.505
AD
32.31
40.94
1.272
1.612
----
0.89 RAD
----
0.035 RAD
AE
2.67
3.68
0.105
0.145
6
AF
FIGURE 1. Outline drawing of electron tube type 8964 - Continued.
