MIL-PRF-1/1754B
Dimensions
Ltr
Millimeters
Inches
Inspection
Min
Max
Min
Max
E
88.27
89.79
3.475
3.535
R
----
68.25
----
2.687
Y
15.32
15.67
.603
.617
AC
2.92
3.43
.115
.135
AD
----
3.96
----
.156
AE
14.28
----
.562
----
AH
37.34
37.54
1.470
1.478
AK
34.24
34.44
1.348
1.356
AM
47.24
48.01
1.860
1.890
AN
47.24
48.01
1.860
1.890
Conformance inspection, part 1
F
30.58
32.92
1.204
1.296
J
40.89
43.23
1.610
1.702
M
22.45
24.08
.884
.948
N
30.58
32.92
1.204
1.296
P
63.25
63.75
2.490
2.510
S
190.50
195.22
7.500
7.686
V
75.95
76.45
2.990
3.010
Conformance inspection, part 2
K
.79
----
.031
----
L
66.19
68.63
2.606
2.702
T
7.01
7.26
.276
.286
W
26.97
28.55
1.062
1.124
X
20.96
21.29
.825
.838
Z
13.51
13.84
.532
.545
AA
5.94
6.76
.234
.266
AB
4.17
4.42
.164
.174
AF
19.05
----
.750
----
AG
3.18
4.75
.125
.187
Nominal
A
139.83
5.505
B
11.10
.437
C
20.83
.820
D
14.76
.581
G
86.11
3.390
H
69.85
2.750
U
15.88
.625
AJ
4.17
.164
AL
95.25
3.750
FIGURE 1. Outline drawing of electron tube type DOD-032 - Continued.
8
