INCH-POUND
MIL-PRF-1/1754B
18 July 2002
SUPERSEDING
MIL-PRF-1/1754A
30 April 1997
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, MAGNETRON
TYPE DOD-032 *
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION:
Coaxial, tunable frequency 8,500 to 9,600 MHz, pulsed, integral magnet, 85 kW rated peak power output.
ABSOLUTE RATINGS:
ib
Tuner torque
rrv
tpc
tk
If
if(surge)
Ef
Parameter:
a
inch-ounce
kV/µs
µs
sec
A
a
V
Unit:
2.0
----
3.6
12
160
75
20
15
Maximum
----
Minimum
0.2
150
----
----
90
----
12
5/ 15/
6/
7/
3/
----
ABSOLUTE RATINGS:
Temperature
Pressurization
Du
Parameter:
Pi
pi
VSWR
(output)
(input)
(input bushing)
(body)
psia
psia
ºC
ºC
----
Unit:
W
kW
----
45
165
125
1.5:1
370
0.00125
45
370
Maximum
15
-55
-55
----
----
----
Minimum
15
4/
(Note 6)
(Note 5)
PHYSICAL CHARACTERISTICS:
See note 28
See figure 1
Marking:
Dimensions:
Unipotential
Any
Cathode:
Mounting position:
8/
Flange
Magnet isolation:
Mounting support:
13.5 pounds
WR-112 (figure 1)
Weight:
Coupling:
Forced air 9/
24/ 25/
Cooling:
* Replaces Varian type number VMX-1135.
AMSC N/A
1 of 9
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
