MIL-PRF-1/1753C
Frequency
F1 = 7,800 MHz
F2 = 8,100 MHz
F3 = 8,500 MHz
TEST CONDITION (1): 24/ 25/
Parameter:
Ef
tpc
rrv
Du
Ib
VSWR
T (body)
F
V
µs
kV/µs
----
mA dc
----
ºC
Freq
Unit:
Maximum
----
0.5
160
----
----
1.1:1
115
----
7
----
----
0.00125
18.75
----
----
F1,F2,F3
Minimum
----
0.3
90
----
----
----
55
----
5/
6/ 7/
(Note 5)
TEST CONDITION (2): 24/ 25/
Parameter:
Ef
tpc
rrv
Du
Ib
VSWR
T (body)
F
V
µs
kV/µs
----
mA dc
----
ºC
Freq
Unit:
Maximum
----
0.9
160
----
----
1.1:1
115
----
7
----
----
0.00125
18.75
----
----
F1,F2,F3
Minimum
----
0.7
90
----
----
----
55
----
5/
6/ 7/
(Note 5)
GENERAL:
Qualification - Required.
Holding period = 48 hours minimum.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
Service-life guarantee in lieu of life-testing shall be forwarded and subject to approval from the qualifying activity.
2
