MIL-PRF-1/1734C
TABLE I. Testing and inspection.
Method
Limits
Inspection
Unit
Test
Symbol
Conditions
MIL-STD-1311
Min
Max
Qualification inspection
1011
MIL-STD-202, method 103B,
1
---
---
---
---
Humidity
test condition B
Barometric pressure
---
MIL-STD-202, method 105C,
1
---
---
---
---
(altitude)
test condition C
Thermal shock
---
MIL-STD-202, method 107,
1
---
---
---
---
test condition B
Conformance inspection,
part 1
Ef = 12.5 ± 0.5 V ac
Heater current
4289
If
1.8
2.5
A
Pulse voltage
4306
1
epy
14.0
18.0
kV
Power output
4250
1
Po
46.8
61.2
W
RF bandwidth (1)
4308
1
BW
---
MHz
1.9
tpc
Minor lobe ratio (1)
4308
1
Ratio
9.0
---
dB
ĆF
Frequency pulling factor
4310
1
---
15
MHz
RF bandwidth (2)
4308
2
BW
---
MHz
1.9
tpc
Frequency
---
3
F
16,465 16,53 MHz
5
Minor lobe ratio (2)
4308
2
Ratio
9.0
---
dB
Pulse stability
4315
5/
2
MP
---
.25
%
Conformance inspection,
part 2
Pressurizing
4003
40 pounds-force per square inch,
1
---
---
---
---
input and output assemblies. 3/
RF bandwidth (3)
4308
3
BW
---
MHz
1.9
tpc
See footnotes at end of table.
