MIL-PRF-1/1709B
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Conformance inspection, part 1
C
.216
.226
5.49
5.74
E
2.100
2.120
53.34
53.85
G
.900
---
22.86
---
H
----
.130
----
3.30
Conformance inspection, part 2
B
3.245
3.255
82.42
82.68
J
---
1.500
---
30.10
Periodic inspection 9/
44°
46°
A
D
.235
.265
5.97
6.73
F
3.610
3.640
91.69
92.46
NOTES:
1. The reservoir overall dimensions shall not exceed the dimensional requirements and shall be physically and functionally
compatible and interchangeable in all applications to the tube types in 7/.
2. Silver plate 100 msi minimum, semi-bright nickel, or equivalent.
FIGURE 1. Outline drawing of electron tube type 8919.
4
