MIL-PRF-1/1702C
Dimensions
Ltr
Inches
Millimeters
Notes
Min
Max
Min
Max
Conformance inspection, part 2
A
1.815
1.875
46.10
47.62
B
---
1.534
---
38.96
C
---
1.475
---
37.46
D
1.289
1.329
32.74
33.76
E
0.970
1.010
24.64
25.65
F
0.462
0.477
11.73
12.12
J
0.766
0.826
19.46
20.98
N
1.025
1.035
26.04
26.29
2, 10
R
0.655
0.665
16.64
16.89
2, 10
T
0.213
0.223
5.41
5.66
3, 10
U
0.315
0.325
8.00
8.26
2, 3, 10
Conformance inspection, part 3
4
G
---
0.040
---
1.02
H
0.125
0.185
3.18
4.70
K
0.025
0.046
0.64
1.17
L
1.234
1.264
31.34
32.11
M
1.180
1.195
29.97
30.35
P
0.752
0.792
19.10
20.12
S
---
0.545
---
13.84
V
---
0.086
---
2.18
W
---
0.100
---
2.54
Y
0.105
0.145
2.67
3.68
Z
0.650
0.850
16.51
21.59
Electrode contact areas
1, 11
AA
0.035
0.361
0.89
9.17
2
AB
1.185
1.265
30.10
32.13
2
AC
1.534
1.728
38.96
43.89
3
AD
1.475
1.815
37.46
46.10
2, 3
FIGURE 1. Outline drawing for electron tube type 8745 - Continued.
