MIL-PRF-1/1664B(NAVY)
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Qualification inspection
A
----
5.800
----
147.32
C
----
3.000
----
76.20
G
----
2.190
----
55.63
M
----
1.100
----
27.94
Conformance inspection, part 1 (see 22/ of table I)
B
0.866
0.926
22.00
23.52
D
----
1.922
----
48.82
E
0.995
----
25.27
----
F
----
0.250
----
6.35
L
0.129 R
0.141 R
3.28 R
3.58 R
Conformance inspection, part 2
H
0.980
1.020
24.89
25.91
N
1.745
1.755
44.32
44.57
P
1.345
1.355
34.16
34.42
R
0.111
0.121
2.82
3.07
Nominal
J
1.312
33.32
K
2.312
58.72
NOTES:
a. Anode temperature shall be measured at this point.
b.
Bushing temperature shall be measured at this point.
c.
Jettron Products, Inc. Connector No. 90-001, or equivalent.
d.
Protective enclosure.
e.
This dimension applies to depth of "O" ring groove.
FIGURE 1. Outline drawing of electron tube type 8827 - Continued.
6
