MIL-PRF-1/1647E
Dimensions
Millimeters
Inches
Ltr
Minimum
Maximum
Minimum
Maximum
A
12.7 Nominal
0.50 Nominal
B
-----
25.4
-----
1.00
C
-----
25.4
-----
1.00
NOTE: Axis of tube and centers of lamps lie in plane of paper.
FIGURE 2. Position of tube for photosensitivity test.
