MIL-PRF-1/1647E
Dimensions
Ltr
Millimeters
Inches
CONFORMANCE INSPECTION, PART 2
Min
Max
Min
Max
A
15.09
15.85
0.594
0.624
B
------
76.20
-----
3.000
C
53.34
53.85
2.100
2.120
E
8.48
8.99
0.334
0.354
G
6.22
6.48
0.245
0.255
J
------
4.45
-----
1.750
L
1.78
2.16
0.070
0.085
M
8.43
8.76
0.332
0.345
N
12.19
12.83
0.480
0.505
REFERENCE DIMENSIONS
F
6.35
0.250
H
7.95
0.313
K
1.60
0.063
FIGURE 1. Outline drawing of electron tube type 8767.
5
