INCH-POUND
MIL-PRF-1/1623C
9 July 1998
SUPERSEDING
MIL-E-1/1623B
11 May 1976
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, TRAVELING WAVE
TYPE 8175 1/
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: 1-kw power output amplifier, 2.9 to 3.1 GHz, periodic-permanent magnet focused.
ABSOLUTE RATINGS: See 1/ of table I.
Parameter:
Ef
eb
ik
Iw
iw
Pp
Pi (rf)
Du
tp
tk
Unit:
V
kv
a
mA
ma
W
w
----
sec
s
Maximum
6.6
8
1.7
3.6
650
82
2
0.006
10
----
Minimum
6.0
6
----
----
----
----
----
2/
3/
120
PHYSICAL CHARACTERISTICS:
Dimensions:
Marking:
See figure 1
5/
All metal shell
DC connectors:
Construction:
See figure 1
RF connectors:
Weight:
14.5 pounds (max)
See figure 1
Cooling:
Mounting position:
Forced air 4/
Any
TEST CONDITIONS:
Parameter:
Ef
eb
pi (rf)
Du
tp
tk
Frequency
Unit:
V
kv
w
---
sec
F
GHz
s
1
2.9
120
6/
5.5
6.3
0.0055
Test condition 1:
0
2
3.0
120
5.5
6.3
0.0055
Test condition 2:
0.001
6/
3
3.1
120
5.5
6.3
0.0055
Test condition 3:
0.5
6/
120
5.5
6.3
0.0055
Test condition 4:
1.5
6/
GENERAL:
Qualification - Required. 7/
_______
1/ Formerly type 334H
AMSC N/A
1 of 6
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
