MIL-PRF-1/1341A
TABLE I. Testing and inspection. Continued
Acceptance
Limits
level
Requirement or Test
Notes
Conditions
Symbol
Unit
Min
Max
( See note 10)
Acceptance inspection
Part 3 (Life)
---
Life test
Group D;
Light =20 ft. L;
---
t
5W
---
hrs
Eb2= 2750 Vdc
Life test End Point
Line Width "A"
Light = 16ft.L
Width
---
0.65
mm
----
Line Width "B"
Light = 16 ft. L
Width
---
0.65
mm
ĆEc
Modulation
Light = 16ft. L
---
38
Vdc
Preparation for delivery
6
----
----
---
---
----
NOTES:
1.
This value is recommended only for low velocity deflecting and low ambient light levels.
2.
All light-dependent tests to be measured with a 1-1/8 inch vertical end 1-9/16 inch horizontal, 35 to 105 line raster.
Photocell is to have one-inch active aperture and can be calibrated in foot-lamberts, similar to Photovolt Corporation Type
200-A or equivalent.
3.
All tests applicable herein shall be performed during Preproduction Sample Approval Inspection; however, these 5 tests
normally are performed during Preproduction Sample Approval Inspection only.
4.
The acceptance level for the combined defectives attributes in acceptance inspection, part 1 (production), excluding
mechanical and blemishes, shall be one percent.
5.
The minimum useful scan I the major dimension D1D2, shall be 2-3/4 inches. The minimum useful scan in the minor
direction, D3D4, shall be 1-1/8 inches.
6.
Tubes shall be prepared for domestic or overseas shipment, as specified in the contract or order, in accordance with
Specification MIL-DTL-75.
7.
Identification marking of product shall be in accordance with MIL-PRF-1, except for the following
a.
Manufacturer's qualification code-letter shall not be used in the product identification marking.
b.
If any specification requirements waiver has been granted, the product-identification marking shall consist of the
type number only
8.
The Preproduction Sample Approval requirements in Electronics Command Drawing ECOM- DWG SC-A-46600 hereby
replace any Qualification requirements referable to the product covered herein (See Note 9 below).
9.
Information pertaining to Preproduction Sample Approval testing may be obtained from Defense Supply Center
Columbus, Code DSCC-VQE P.O. Box 3990, Columbus, OH 43216-5000. See the contracting officer for copies of
Electronics Command Drawing SC-A-46600.
10. This specification sheet uses accept on zero defect sampling plan in accordance with MIL-PRF-1, table III.
4
