INCH-POUND
MIL-PRF-1/1295F
9 July 2004
SUPERSEDING
MIL-PRF-1/1295E
19 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 6842
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION:
Pentode, high voltage, sharp cutoff.
Outline
---
5-2 (EIA) (see figure 1 for dimensions).
Base
---
E7-1.
Envelope
---
T5-1/2.
Cathode
---
Coated unipotential.
Base connections:
Pin no.
1
2
3
4
5
6
7
Cap
Element
G2
H
K, G3
G1
K, G3
H
K, G3
a
ABSOLUTE RATINGS:
Parameter:
Ef
Eb
Ec1
Ec2
Ehk
Rg1
Ib(ave)
ib
Pp
Pg2
Unit:
V
V dc
V dc
V dc
V dc
Meg
ma
ma
W
W
Maximum:
6.9
4,000
---
150
0.1
10
100
8
.5
±300
Minimum:
5.7
---
-100
---
---
---
---
---
---
---
Test conditions:
6.3
1,500
-1.5
100
---
---
---
---
---
----
See footnotes at end of table I.
GENERAL: Qualification - Not required.
First article testing: Required (See MIL-PRF-1, appendix F).
AMSC N/A
FSC 5960
