MIL-PRF-1/1204H
Dimensions
Pin No
Element
Ltr
Inches
Millimeters
Grid No. 1
1
Min
Max
Min
Max
Deflector plate D1
2
Qualification inspection
Deflector plate D3
3
F
Base: E9-1 except for pin length
Heater
4
Conformance inspection, part 2
Heater cathode
5
A
2.917
3.004
74.09
76.30
Deflector plate D2
6
B
.750
.875
19.05
22.23
Anode No. 2
7
C
2.687
2.749
68.25
69.82
Anode No. 1
8
D
.230
.255
5.84
6.48
Deflector plate D4
9
E
.350
---
8.89
---
NOTE: Useful screen radius.
FIGURE 1. Outline drawing of electron tube type 1DP1.
