INCH-POUND
MIL-PRF-1/1204H
2 July 2004
SUPERSEDING
MIL-PRF-1/1204G
29 June 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 1DP1
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Miniature 1-inch, electrostatic deflection and focus.
PIN CONNECTIONS AND DIMENSIONS. See figure 1.
ABSOLUTE RATINGS:
Alt
Rd
Zd
Rg
Eb2
Eb1
Ed
Ec1
Ef
Parameter:
MegΩ
MegΩ
MegΩ
ft
V dc
V dc
V
V dc
V
Unit:
0, -100
400
300
1,000
2
2
2
60,000
6.9
Maximum:
5.7
---
---
---
---
---
---
---
---
Minimum:
Test conditions:
6.3
Adjust
---
Focus
800
---
---
---
---
See footnotes at end of table I.
GENERAL:
First article inspection: Required. 4/
AMSC N/A
FSC 5960
