MIL-PRF-1/1162E
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Qualification inspection
U
Bulb contact: J1-21
V
Base: B5-57 or B7-51
Conformance inspection, part 2
A
17.245 17.995
438.02
457.07
B
---
10.620
---
269.75
C
1.380
1.500
35.05
38.10
D
4.500
---
114.30
---
E
9.250
9.620
234.95
244.35
F
10.380 10.620
263.65
269.75
G
---
.750
---
19.05
J
6.870
7.620
174.50
193.55
10
M
Reference dimensions
(see note 3)
K
.650
16.51
L
20.000
508.00
N
42.000
1066.80
P
.380
9.65
Q
2.000
50.80
50
R
S
.242
6.15
T
2.900
73.66
NOTES:
1. Reference line is determined by position where JEDEC gauge G-112 will rest on bulb cone.
2. Useful screen radius.
3. Reference dimensions are for information only and are not required for inspection purposes.
FIGURE 1. Outline drawing of electron tube type 10KP7A.
5
