INCH-POUND
MIL-PRF-1/1162E
4 August 2009 __
SUPERSEDING
MIL-PRF-1/1162D
29 June 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 10KP7A
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Magnetic deflection and focus.
PIN CONNECTIONS AND DIMENSIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
Ec2
Eb
Ehk
Rg1
Alt
MegΩ
Unit:
V
V dc
V dc
V dc
V dc
ft
125
770
11,000
60,000
1/
Maximum:
6.9
0, -180
--- 1/
---
----
---
7,000
Minimum:
5.7
---
Test condition:
6.3
Adjust
250
9,000
---
---
---
See footnotes at end of table I.
GENERAL:
Qualification - Required.
AMSC N/A
FSC 5960
