INCH-POUND
MIL-PRF-1/1147C
4 August 2009 ___
SUPERSEDING
MIL-PRF-1/1147B
29 June 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, MICROWAVE NOISE SOURCE
TYPE 6782
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Gaseous discharge diode, S band. 12/
Cathode: Filamentary type.
Dimensions: In accordance with outline drawing (see figure 3).
Base: Miniature Bi-pin, in accordance with outline drawing (see figure 3).
Mounting position: Any.
ABSOLUTE RATINGS:
Parameter:
If
Ib
Epp
TA
T Bulb
C
C
Unit:
ma
mA dc
V ac
Maximum:
---
---
---
+85
+125
Minimum:
---
---
2,000
-55
---
Test conditions:
0
250
---
---
---
See footnotes at end of table I.
____________________________________________________________________________________________
GENERAL:
The Preproduction sample approval requirements in CECOM Drawing SC-A-46600 hereby replace any qualification
requirements existing in or otherwise referable to the data in this specification sheet.
Qualification Not required. 13/ 14/
Holding Period 168 hours.
AMSC N/A
FSC 5960
