MIL-PRF-1/1112H
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Qualification
E
4.600
4.850
116.84
123.19
G
.172
.203
4.36
5.16
M
1.563
1.688
39.70
42.88
Q
---
9.000
---
228.60
R
---
7.750
---
196.85
S
5.719
5.781
145.15
146.73
U
---
4.250
---
107.95
W
43.5°
46.5°
Conformance inspection, part 2
A
17.250
19.000
438.15
482.60
B
6.844
6.906
173.84
175.41
C
5.344
5.406
135.74
137.31
D
10.000
10.250
254.00
260.35
F
2.625
2.875
66.67
73.03
H
3.375
3.438
85.73
87.33
J
---
4.565
---
115.95
N
1.188
1.313
30.17
33.35
T
2.844
2.906
72.23
73.81
V
3.024
3.039
76.81
77.19
Y
---
2°
Z
115°
125°
Nominal dimensions (see note 2)
P
.625
15.87
X
5°
5°
NOTES:
1. Metric equivalents (to the nearest 0.01 mm) are given for general information only.
2. Dimensions without tolerances are for information only and are not required for inspection purposes.
3. Output connector shall mate with connector UG-1126/U.
4. Connectors shall mate with Plug M39012/16-0001.
5. Provision shall be made for 1.250 inch (31.75 mm) tuning travel.
6. Axis of tube shall be perpendicular to collector end-plate within .015 inch (0.38 mm) for every inch, assuming parallel
tuning.
7. Allowable deviation of connectors from true position on centerline.
8. Allowable deviation of seal-off tip from true position on centerline through mounting holes as shown.
9. Pictorial configuration is for reference purposes only.
10.
Tuning screws should be free and clear of all paint.
FIGURE 1. Outline drawing of electron tube type 8493 - Continued.
