INCH-POUND
MIL-PRF-1/1049H
16 June 2004
SUPERSEDING
MIL-PRF-1/1049G
25 June 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, IMAGE CONVERTER
TYPE 6914
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION:
Infrared sensitive (S1 photocathode surface; P-20 phosphor image screen).
See figure 1.
W eight: 3 ounces (85 grams) nominal.
Mounting position: Any.
ABSOLUTE RATINGS:
Parameter:
ib 2/
Ib
Rb
TA
Eb
Light flux
µA dc
µA dc
MΩ
°C
Unit:
kV dc
lux
Maximum:
16
---
3.5
68
---
0.35
Minimum:
---
---
----
-54
----
----
Test condition:
16
1/
----
---
100
20 to 23
See footnotes at the end of table I.
GENERAL:
Qualification - Required.
Holding period: 4/
Stabilization: 3/
AMSC N/A
FSC 5960
