INCH-POUND
MIL-PRF-1/10J
14 April 2005
SUPERSEDING
MIL-E-1/10H
17 February 1981
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 5751
This specification sheet is inactive for
new design after 11 August 2000.
This specification sheet is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described
herein shall consist of this document and MIL-PRF-1.
DESCRIPTION: Twin triode, miniature, high Mu
Outline - - - 6-2 (EIA)
Base
- - - E9-1
Envelope - - - T6-1/2
Cathode - - - Coated unipotential
Base connections:
Pin No. - - - 1 2 3 4
5
6 7
8
9
Element - - - 2a 2g 2k h
h
1a 1g
1k
hct
ABSOLUTE-MAXIMUM RATINGS:
Parameter:
Ef
Eb
Ec
Ehk
Rg/g
Ik/k
Pp/p
TE
Alt
°C
MegΩ
Unit:
V
Vdc
Vdc
v
mAdc
W
ft
Maximum:
13.8
330
0, -50
100
0.5
6
0.8
(see note 1)
+165
Maximum:
6.9
---
---
---
---
---
---
---
---
Minimum:
11.4
---
---
---
---
---
---
---
---
Minimum:
5.7
---
---
---
---
---
---
---
---
Test conditions:
12.6
250
-3
0
---
---
---
---
GENERAL:
Qualification: Not required.
Reliable tube
AMSC N/A
FSC 5960
