MIL-E-1/605E
Dimensions
Ltr
Inch
mm
Min
Max
Min
Max
Qualification
F
1.000
25.40
H
.160
4.06
L
1.750
44.45
Conformance Inspection, Part 1
A
1.276 1.284 32.41 32.61
D
1.216 1.224 30.89 31.09
M
1.750
44.45
Conformance Inspection, Part 2
C
.010 .070 0.25 1.78
J
.248 .250 6.30 6.35
K
.850 .936 21.59 23.77
E
3.125
79.38
Nominal Dimensions
B
.187
4.75
G
.219
5.56
.185
4.70
N
.050 Wide
1.27
.220 Deep
5.59
NOTES:
1. Metric equivalents are based upon 1 inch = 25.4 mm.
2. Nominal dimensions are for information only and are not required for inspection purposes.
3. Base: Peewee 3 Pin, A3-1.
4. Cap: C1-4.
FIGURE 1. Outline drawing of type 6310.
