INCH-POUND
MIL-E-1/605E
17 January 2014
SUPERSEDING
MIL-E-1/605D
13 March 1975
MILITARY SPECIFICATION SHEET
ELECTRON TUBE, KLYSTRON
TYPE 6310
Inactive for new design
after 21 July 1997.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described
herein shall consist of this specification sheet and MIL-PRF-1.
DESCRIPTION: Reflex oscillator, integral cavity, tunable frequency range 8,500 to 10,000 MHz.
ABSOLUTE RATINGS:
Tuner plate
Parameter:
Ef
Ers
Er
Irs
tk
F
Alt
Temperature
Unit:
V
Vdc
Vdc
mAdc
°C
(see note 1)
MHz
ft
Maximum:
7.0
350
-20 to -1,000
42
200
---
10,000
10,000
Minimum:
5.7
---
---
---
---
---
8,500
---
TEST CONDITIONS:
Tuner plate
Parameter:
Ef
Ers
Er
F
temperatures
Unit:
V
Vdc
Vdc
°C
MHz
6.3
300
-55 to -225
(see notes 2 and 3) 9,300 ± 0.3%
PHYSICAL CHARACTERISTICS: (See outline drawing)
GENERAL:
Qualification Required
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
