INCH-POUND
MIL-E-1/384C
17 January 2014
SUPERSEDING
MIL-E-1/384B
2 November 1970
MILITARY SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 6081
Inactive for new design
after 7 March 1997.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described
herein shall consist of this specification sheet and MIL-PRF-1.
DESCRIPTION: ATR, fixed frequency, Fo = 5,640 MHz
ABSOLUTE RATINGS:
Parameter:
Transmitter po
Du
tp
Alt
Unit:
kw
---
µs
ft
Maximum:
---
0.001
1.0
10,000
Minimum:
10
---
---
---
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1.
Mounting position: Any (see table 1, note 2)
TEST CONDITIONS:
σ'
Parameter:
po
prr
tp
Frequencies
Unit:
kw
pps
µs
---
F
MHz
±
Test 1:
20
1,000
1.0
---
F1
5,640
---
Test 2:
70(min)
1,000
1.0
1.03 (max)
F2
5,640 0.1%
Test 3:
300 ± 10
1,000
1.0
1.2(max)
F3
5,640
4%
GENERAL:
Qualification Required
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
