INCH-POUND
MIL-E-1/175K
17 September 2013
SUPERSEDING
MIL-E-1/175J
28 February 2003
MILITARY SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 5902
Inactive for new design
after 7 March 1997.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
Requirements for acquiring the electron tube described
herein shall consist of this document and MIL-PRF-1.
DESCRIPTION: Pentode, subminiature, beam power
Outline
---
3-3 (EIA).
Base
---
E8-10.
Envelope
---
T3.
Cathode
---
Coated uni-potential.
Base connections:
Pin No.
1
2
3
4
5
6
7
8
Element
g1
k, g3
h
k, g3
a
h
g2
k, g3
ABSOLUTE- RATINGS:
Parameter:
Ef
Eb
Ec1
Ec2
Ehk
Rk
Rg1
Ik
Pp
Pg2
TE
Alt
Ohms MegΩ mA dc
°C
Unit:
V
V dc
V dc
V dc
v
W
W
ft
Maximum:
6.6
165
0, -55
155
200
---
0.55
50
3.7
0.4
220
See
note 1
Minimum:
6.0
---
---
---
---
---
---
---
---
---
---
---
Test Conditions: 6.3
110
0
110
0
270
---
---
---
---
---
---
GENERAL:
Qualification Not required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
