MIL-PRF-1/974F
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Qualification inspection
P
Base: B12-43
Q
Bulb contact: J1-25
R
Bulb contact: J1-22
Conformance inspection, part 2
A
9.750
10.250
247.65
260.35
B
2.938
3.063
74.63
77.80
C
1.563
1.688
39.70
42.88
D
1.313
---
33.35
---
E
5.188
5.563
131.78
141.30
F
3.688
4.063
93.68
103.20
G
1.313
1.688
33.35
42.88
10°
20°
10°
20°
J
25°
35°
25°
35°
K
55°
65°
55°
65°
L
85°
95°
85°
95°
M
115°
125°
115°
125°
N
NOTE: Minimum useful screen radius.
FIGURE 1. Outline drawing of electron tube types 3ADP1, 3ADP2, 3ADP7, and 3ADP11.
6
