INCH-POUND
MIL-PRF-1/745H
12 July 1999____
SUPERSEDING
MIL-E-1/745G
28 October 1969
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, KLYSTRON
TYPE 6BL6 *
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Reflex, external cavity, pulse, and CW operation.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
Ec2
Ec3
Er
Ik
Ehk
Pi
tk
Alt
Unit:
V
V dc
V dc
V dc
V dc
mA dc
V dc
W
sec
ft
Maximum
+1.0
350
350
-700
35
+45
12
---
10,000
6.8
Minimum
5.8
-500
---
---
-15
---
-45
---
120
---
PHYSICAL CHARACTERISTICS:
See figure 1
Dimensions:
Coated unipotential
Cathode:
Mounting position:
Any
TEST CONDITIONS:
Parameter:
Ef
Ec1
Ec2
Ec3
Er
Unit:
V
V dc
V dc
V dc
V dc
6.3
0
300
300
Adj for max Po
See footnotes at end of table I.
__________________________________________________________________________________________
GENERAL:
Qualification: Required.
_________
* CAUTION: Tube not designed for applications where hysteresis may affect performance.
AMSC N/A
1 of 5
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
