INCH-POUND
MIL-PRF-1/744J
17 January 2012
SUPERSEDING
MIL-PRF-1/744H
12 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, KLYSTRON
TYPE 6BM6 *
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Reflex, separate cavity, pulse, and CW operation.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
Ec2
Ec3
Er
Ik
Ehk
Pi
tk
Alt
Unit:
V
V dc
V dc
V dc
V dc
mA dc
V dc
W
sec
ft
Maximum
6.9
+1.0
350
350
-700
32
+45
10
---
10,000
Minimum
5.7
-500
---
---
-15
---
-45
---
120
---
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1
Cathode:
Coated unipotential
Mounting position:
Any
TEST CONDITIONS:
Parameter:
Ef
Ec1
Ec2
Ec3
Er
Unit:
V
V dc
V dc
V dc
V dc
Test condition 1:
6.3
0
325
325
Adj for max Po
Test condition 2:
6.3
0
300
300
Adj for max Po
See footnotes at end of table I.
__________________________________________________________________________________________
GENERAL:
Qualification: Not required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
_________
* CAUTION: Tube not designed for applications where hysteresis may affect performance.
